Carbon Graphite Electrode



We have strong market control capabilities. The company adjusts inventory in a timely manner according to market demand, and the supply is sufficient to ensure that the needs of market customers are met.

Our sales network is spread all over the world and has been exported to more than 200 countries including the United States, Mexico, Canada, Spain, Russia, Singapore, Thailand, India, etc.





As an important part of electric arc furnaces, graphite electrodes are mainly used in metallurgy, chemical industry, power and other fields. The main applications of graphite electrodes are introduced below.

1. Iron and steel smelting

Graphite electrodes are widely used in the field of iron and steel smelting, mainly used in electric arc furnace smelting, casting and other processes. Electric arc furnace smelting is one of the important production processes in the steel industry. The quality of graphite electrodes directly affects the smelting efficiency and product quality.

2. Non-ferrous metal smelting

Graphite electrodes are also widely used in the field of non-ferrous metal smelting, mainly used in electrolytic copper, aluminum and other processes. During the electrolysis process, graphite electrodes, as electrode plates, play the role of conducting electricity, transferring heat and bearing current.

3. Chemical Industry

Graphite electrodes are also widely used in the chemical industry, mainly in electrolysis, electrodeposition, electrochemical processing and other processes. For example, graphite electrodes can be used as anodes in the electrolysis process of the chlor-alkali industry, and can also be used in the electrochemical processing of preparing high-purity chemicals and materials.

4. Other fields

In addition to the above-mentioned application fields, graphite electrodes can also be used in the power industry, glass industry, semiconductor industry and other fields. For example, in the power industry, graphite electrodes can be used for electrode grounding, electrode protection and other aspects.





Item	Unit	Nominal diameter mm
		Φ800～Φ960	Φ1020～Φ1400
Resistivity Electrode not more than Joint	μΩ.m	11.0 7.5	13.0 7.5
Flexural strength Electrode not less than Joint	MPa	6.0 13.0	6.0 13.0
Elastic modulus Electrode not more than Joint	Gpa	10.0 14.0	10.0 14.0
Thermal expansion coefficient Electrode not more than Joint	×10-6/℃	3.2 2.8	3.2 2.8
Volume density Electrode not less than Joint	g/cm3	1.58 1.68	1.58 1.68
Ash content not more than	％	0.5	0.5





1. Provide you with the most competitive price

2. Provide you with relevant professional product consultation

3. You can visit our factory in person



We can provide you with free samples, manuals, laboratory test reports, industry reports, etc. Welcome to visit our factory and company.
